Automatic tracking antenna gimbal for UAV signal reception with integrated compass and video output connectors Automatic tracking antenna gimbal for UAV signal reception with integrated compass and video output connectors
1 4

MFD

MFD MINI AAT 자동 추적 안테나 추적 PTZ

$44.00
MFDMN-GC
TYPE: 외부 GPS+자기 나침반 모듈

결제 후 7-15일 이내 배송 예정;

Checkout Securely with

American Express
Diners Club
Discover
Google Pay
JCB
Maestro
Mastercard
PayPal
Union Pay
Visa

주문이 불가능한 고객님께서는 저희에게 연락해 주시기 바랍니다;

Tag : Antenna Tracking Gimbal , Automatic Tracking Antenna , PTZ Tracking , UAV Antenna System , UAV Signal Reception
TYPE: 외부 GPS+자기 나침반 모듈

1. 제품 소개

MyflyDream 미니 석궁 자동 추적 짐벌(CrossbowMini AAT)은 UAV 안테나 시스템을 위해 설계되었습니다. 설계 목표는 UAV 시스템에 전방위 고이득 신호 수신을 제공하는 것입니다. 더 나은 신호 수신 품질을 위해서는 고이득 수신 안테나가 바람직합니다. 그러나 고이득 안테나는 종종 유효 각도가 좁습니다. MFD Crossbow AAT는 UAV 비행 중 방향성 안테나로 최적의 송수신 각도를 유지하는 어려움을 해결하기 위해 설계되었습니다.

CrossbowMini AAT는 추적 대상(드론)의 위도, 경도, 고도가 필요합니다. 이를 위해 다음과 같은 여러 솔루션을 제공합니다:

  • 무선 아날로그 비디오 링크를 통해 추적 대상 정보를 전송합니다. 드론에는 당사의 TeleFlyPro 추적 모듈을 설치하거나 MFDAP/MFD Crosshair AP 비행 컨트롤러를 사용해야 합니다.
  • 일부 고화질 송신기는 내장된 직렬 통신 기능이 있습니다. TeleFlyPro 모듈을 항공기에 설치하여 직렬 포트를 통해 추적 데이터를 Crossbow AAT로 전송할 수 있습니다.
  • MAVLink 프로토콜을 사용하는 디지털 무선을 통해 드론 정보를 전송합니다. 사용자의 시스템에 이미 데이터 무선기와 MAVUnk 프로토콜을 지원하는 비행 컨트롤러가 포함되어 있다면, 데이터 무선기의 TX 라인을 Crossbow AAT와 공유하여 추적을 수행합니다.
  • 기타 독점 프로토콜에 대한 맞춤 해석도 지원합니다. 구체적인 요구 사항은 저희에게 문의해 주십시오.

CrossbowMiniAAT 주요 사양:

2. 설치 및 배선

1. 짐벌 하단에는 표준 1A-20 삼각대 나사산 인터페이스가 있습니다. 견고하고 신뢰할 수 있는 삼각대를 구입하여 AAT를 퀵 릴리스 플레이트에 장착하십시오. 삼각대 퀵 릴리스 플레이트의 회전 방지 돌기가 AAT 하단의 대응 회전 방지 구멍에 삽입되도록 하십시오. AAT는 12V~16V(3S~4S) DC 전원이 필요합니다. AAT 패널에 XT30 소켓이 있으니 호환 가능한 전원에 연결하십시오.

Gimbal wiring diagram

2. 안테나를 AAT의 안테나 장착 브래킷에 단단히 고정하십시오. 강자성 재료가 포함된 안테나는 AAT 내장 나침반 기능에 영향을 줄 수 있으므로 사용을 피하십시오. 가능하면 스테인리스 와이어, 알루미늄 등 비자성 재료를 사용하십시오. 아날로그 비디오 수신기를 짐벌 틸트 서보 뒤쪽의 3핀 소켓에 연결하십시오. 이 소켓의 배선도는 다음과 같습니다:

Wiring diagram for the gimbal's tilt servo

3. 예비 테스트

배선 확인과 삼각대 고정이 완료되면 짐벌 전원을 켜서 테스트하십시오. 정상적인 경우 짐벌 틸트 각도는 0도(수평 방향)로 복귀하며 안테나는 정면을 향합니다. 패널 화면에는 다음 정보가 표시됩니다:

  • Bat#/GPS: 짐벌 현재 전원 전압과 탑재된 GPS 위성 수를 번갈아 표시합니다.
  • Dst: 현재 집 위치로부터 거리. N/A는 사용 불가를 의미합니다.
  • Alt: 집 위치 대비 현재 항공기 고도. N/A는 사용 불가를 의미합니다.
  • Azim: 집 위치 대비 현재 항공기 방위각. N/A는 사용 불가를 의미합니다.
  • VLink/DLink: 현재 다운링크 신호 품질(80%). 비디오 또는 디지털 링크 사용 여부에 따라 Wuink 또는 DLinkDr가 표시되며, 짐벌 베이스의 방위각을 나타냅니다.

항공기와 짐벌이 모두 전원이 켜져 있으면 짐벌의 비디오 출력 포트에 탑재된 카메라 영상이 표시되어야 합니다. 화면의 WLink는 신호 링크 품질을 나타냅니다. Vink 표시가 신호 세기 0을 나타내면 비행 컨트롤이 VB1 인코딩, V2 버전 기술로 설정되어 있는지 확인하십시오.

4. 현장 사용 절차:

  1. 항공기와 무선기 전원을 켭니다. 무선기의 VLink에 표시된 신호 품질이 0.2 이상인지 확인합니다. 위성 수가 충분하면(예: 8개 이상) 비행 컨트롤이 Set Home 작업을 수행합니다. 통신이 정상이라면 짐벌의 작은 화면에 "Set Home"이 표시되고 홈 위치가 초기화됩니다.
  2. 오른쪽 버튼을 짧게 눌러 짐벌의 홈 위치를 설정할 수도 있습니다.
  3. 항공기가 10미터 떨어지면 무선기가 자동 추적을 시작합니다.

짐벌 메뉴 조작 안내

메인 화면 버튼 조작:

  • 왼쪽 버튼: 길게 눌러 메뉴에 진입합니다.
  • 오른쪽 버튼: 짧게 눌러 해당 항목을 선택합니다.

메뉴 화면:

  • Yaw Trimm: 짐벌 추적 편차를 도 단위로 보정합니다. 오른쪽 버튼으로 -15에서 +15까지 값을 조정합니다.
  • CalCompass: 내부 자기 나침반 보정을 위해 AAT 전체를 수평으로 최소 한 바퀴 회전시킵니다.
  • CompassMMod: 나침반 사용 모드(옵션: OnlyPoweron, Always, Never).
  • AIways: 항상 자기 나침반을 사용합니다.
  • Exit: 메뉴를 종료합니다.

짐벌 보정 및 조작에 대한 자세한 내용은 사용자 매뉴얼을 참조하거나 지원팀에 문의해 주십시오.
